12 kWp hybrid PV kit – DEYE SG01HP3 10 kW 3-phase HV on/off-grid inverter + energy storage 3 × DEYE BOS-G PRO 5.12 kWh LiFePO4 + PDU2 (15.36 kWh) + 17 × Jetion 705 W

PRE-ORDER · lead time: 10 days.

Hybrid photovoltaic kit 12 kWp – DEYE SG01HP3 10 kW 3-phase HV on/off-grid inverter + energy storage 3 × DEYE BOS-G PRO 5.12 kWh LiFePO4 + PDU2 (15.36 kWh) + 17 × Jetion 705 W

PV kit + energy storage for the HOME / SMALL BUSINESS segment, based on the DEYE SG01HP3 10 kW hybrid inverter (3-phase, HV). Includes 17 Jetion 705 W panels totalling 11.98 kWp and a 3× DEYE BOS-G PRO storage system with a combined capacity of 15.36 kWh together with the Deye HV BOS-G-PDU-2 control module. The configuration enables storing the generated energy and using it in a three-phase installation.

Kit contents

• 17 × Jetion 705W photovoltaic panel (SKU: ME0004)
• 1 × DEYE 10kW SG01HP3 3-phase high-voltage hybrid inverter (SKU: ME0009)
• 3 × DEYE BOS-G PRO 5.12 kWh HV energy storage (SKU: ME0041)
• 1 × Deye HV BOS-G-PDU-2 control module (SKU: ME5926)

Key parameters

• Kit type: PV + STORAGE + INVERTER
• Segment: HOME / SMALL BUSINESSES
• System voltage: HV
• Phase configuration: 3-phase
• Inverter power: 10 kW
• PV system capacity: 11.98 kWp
• Energy storage capacity: 15,36 kWh

Benefits of the configuration

• 17 Jetion 705 W panels create a system with a total peak power of 11.98 kWp.
• The DEYE SG01HP3 10 kW hybrid inverter operates in a 3-phase HV system and supports integration with the storage system.
• The 3× DEYE BOS-G PRO storage provides 15.36 kWh LiFePO4 capacity for storing energy.
• The Deye HV BOS-G-PDU-2 control module facilitates cooperation between the inverter and the batteries within the kit.

Applications

Designed for homes and small businesses that require a PV solution with storage and three-phase HV supply. Ideal wherever storing energy from a photovoltaic installation and later using it in a three-phase system is important.

Scope of supply and system selection

The scope of supply includes only the components listed in the "Kit contents" section. Cabling, protection devices, the mounting structure and other accessories must be selected separately unless explicitly listed in the contents.
