DEYE Hybrid inverter 12kW SG01HP3 3-phase high voltage
Product code: ME0008_GB
Shipping costs are not included in the price.
Shipping costs are not included in the price.
Shipping & Returns
Master Energy | Master Investment Sp. z o.o.
1. Right of Return (14 Days)
Individual consumers (B2C) have the right to withdraw from the contract and return purchased items within 14 calendar days from delivery without stating a reason.
2. How to submit a return or claim?
- 📧 E-mail: bok@masterenergy.eu
- 📞 Phone: +48 884 570 201
- 🏢 Registered Address: Master Investment Sp. z o.o., Rondo ONZ 1, 00-124 Warsaw, Poland (VAT ID: PL7010345632)
3. Complete terms and conditions
Detailed freight information, pallet shipping methods, and B2B commercial terms are available at our dedicated information page:
Payment methods
Ask about the product
Administratorem danych osobowych jest Master Investment sp. z o.o.. Przetwarzamy je w celu przesłania odpowiedzi na zapytanie. Więcej informacji dotyczących przetwarzania danych osobowych znajduje się w polityce prywatności.
Product features
Inverter parameters
- Weight [kg] 30.5
- Manufacturer code SUN-12K-SG01HP3-EU-AM2
- Dimensions 408 x 638 x 237 mm
- Weight 31-50 kg
- Inverter power 10-15 kW
- Inverter type Hybrid
- Number of phases Three-phase
- Battery voltage High voltage (HV)
- Power [kW] 12
Description
The Deye 12kW SG01HP3 hybrid inverter is a modern and reliable heart of a photovoltaic installation, ensuring maximum efficiency and operational safety. Perfect for three-phase systems, it allows you to simultaneously charge batteries and power the building. The high-voltage design guarantees stability and lower energy loss. The device is distinguished by solid workmanship, intuitive online monitoring and a long manufacturer's warranty. It is an excellent choice for people looking for quality, energy independence and full control over the PV system.
Key features
- Hybrid grid-energy storage operation
- Deye high efficiency and reliability
- Monitoring via application or web portal
- Quiet operation and modern design
- Long manufacturer's warranty
Technical parameters
- Rated power: 12000W
- Type: 3-phase, hybrid, high voltage
- PV input voltage: up to 500V
- Battery charging current: up to 240A
- Communication: Wi-Fi, RS485, CAN
- Operating temperature range: -25°C to +60°C
Warranty: 10 years
