Energy Storage SigenStor BAT 6.0 Battery Module

The SigenStor BAT 6.0 energy storage is a modular LiFePO4 battery with a total capacity of 6.02 kWh and a usable capacity of 5.84 kWh. Designed for long life and safe operation — cells with a capacity of 314 Ah and a declared lifespan of up to 10,000 cycles.

Manufacturer: Sigenergy (Sigenergy Technology Co., Ltd.). The company provides a series of SigenStor energy storage systems designed to work with its own inverters (SigenStor EC, Sigen Hybrid SP2/TP2). In the technical data sheets, the manufacturer provides test conditions and compliance with relevant international standards.

Electrical Parameters

• Battery Type: LiFePO4
• Cell Capacity: 314 Ah
• Cycle Life: 10000 cycles (according to the manufacturer, test conditions: 25±2°C, 0.5C)
• Total Energy Capacity: 6.02 kWh
• Usable Capacity: 5.84 kWh (100% DoD, test conditions: 0.2C at 25°C, at the beginning of life)
• Depth of Discharge (DoD): 100%
• Max. Charging/Discharging Power: 3000 W
• Peak Power (10 s): 4500 W
• Number of Modules per Controller: 1–6 pcs

Mechanical and Environmental Parameters

• Weight: 62 kg
• Dimensions (W / H / D): 767 / 270 / 265 mm
• Cooling: natural convection
• Protection Class: IP66
• Storage Temperature Range: -25 ~ 60 °C
• Operating Temperature Range: -20 ~ 55 °C
• Relative Humidity: 5% ~ 95%
• Max. Operating Height: 4000 m
• Installation Method: floor standing / wall mounting
